Four Wheel Drive |
Low Ground Pressure (LGP) |
| Ground Pressure |
Approx 9 PSI |
4.2 PSI |
| Height |
9' 8'' height |
9' 6'' height |
| Width |
8' 5" width |
8' 6" width |
| Length |
21' 2" length |
24' 2" length |
| Weight |
25,000 lbs. with attachment |
29,000 lbs. with attachment |
| Drives |
Hydrostatic |
Dual Hydrostatic |
| Engine |
Cummins Diesel Tier III
QSB 220 HP |
Cummins Diesel Tier III
QSB 250 HP |
| Brakes |
Wet Brakes* new axles
Full locking differential options |
Fail Safe |
| Fuel Capacity |
60 Gallon (Average consumption 10-12 gal/hr) |
80 Gallon (Average consumption 12-14 gal/hr) |
| Controls |
Steering Wheel
Right Joystick: boom and cutter head
Single Pedal: operates travel |
Dual Joystick
Right: boom and cutter head
Left: operates travel |
| Winch |
20,000 lb. winch with 150' cable and wireless remote |
20,000 lb. winch with 150' cable and wireless remote |
| Tires/Tracks |
26.5" 16 ply Forestry Tires |
Steel and Rubber |
| Cab |
Pressurized climate control cab with Heating/Air-conditioning
|
Heating/Air-conditioning |
| Cutter Head |
Fecon BH 120 HD or 200
Other cutter head options available |
Fecon BH 120 |
| Full Tilt Height |
Approximately 11' |
Approximately 11' |
| Road
Speed |
13 mph |
8 mph |
| Transfer Case |
Two speed transfer case |
N/A |
| Safety Features |
Rear view camera for better rear visibility
Forward facing & rear facing flood lights
Full Lexan Windows
Lockable front & rear differentials
Parking brakes are fail safe
Master electric shutdown switch in engine compartment |
ROPS & FOPS Certified
Rear view camera for better rear visibility
Forward facing & rear facing flood lights
Full Lexan Windows
Parking brakes are fail safe
Master electric shutdown switch in engine compartment |
| Special Features |
Pilot operated valve option
Easy access engine compartment
12 volt accessory power outlet
On board compressed air
Single function lever or thumb switch opens/closes gate
Reversing fan
No need for travel permits
Hydraulic shift on the go
Lockable cab and engine compartment doors
Dual in-tank hydraulic oil filters |
Pilot operated valve option
Easy access engine compartment
12 volt accessory power outlet
On board compressed air
Single function lever or thumb switch opens/closes gate
Reversing fan
No need for travel permits
Hydraulic shift on the go
Lockable cab and engine compartment doors
Dual in-tank hydraulic oil filters |
(all specifications subject to change at any time)
| |
Four Wheel Drive |
Low Ground Pressure (LGP) |
| Ground Pressure |
Approx 0.62 Bar |
0.29 Bar |
| Height |
2.95 m height |
2.90 m height |
| Width |
2.57 m width |
2.59 m width |
| Length |
6.45 m length |
7.37 m length |
| Weight |
11,300 Kg with attachment |
13,200 Kg with attachment |
| Drives |
Hydrostatic |
Dual Hydrostatic |
| Engine |
Cummins Diesel Tier III
QSB 164 KW |
Cummins Diesel Tier III
QSB 186 KW |
| Brakes |
Wet Brakes* new axles
Full locking differential options |
Fail Safe |
| Fuel Capacity |
227 Liter (Average
consumption 38-45 L/hr) |
303 Liter (Average
consumption 45-53 L/hr) |
| Controls |
Steering Wheel
Right Joystick: boom and cutter head
Single Pedal: operates travel |
Dual Joystick
Right: boom and cutter head
Left: operates travel |
| Winch |
9072 Kg winch with 45.7 m cable and wireless remote |
9072 Kg winch with 45.7 m cable and wireless remote |
| Tires/Tracks |
26.5" 16 ply Forestry Tires |
Steel and Rubber |
| Cab |
Pressurized climate control cab with Heating/Air-conditioning
|
Heating/Air-conditioning |
| Cutter Head |
Fecon BH 120 HD or 200
Other cutter head options available |
Fecon BH 120 |
| Full Tilt Height |
Approximately 3.35 m |
Approximately 3.35 m |
| Road
Speed |
20.9 kph |
12.9 kph |
| Transfer Case |
Two speed transfer case |
N/A |
| Safety Features |
Rear view camera for better rear visibility
Forward facing & rear facing flood lights
Full Lexan Windows
Lockable front & rear differentials
Parking brakes are fail safe
Master electric shutdown switch in engine compartment |
ROPS & FOPS Certified
Rear view camera for better rear visibility
Forward facing & rear facing flood lights
Full Lexan Windows
Parking brakes are fail safe
Master electric shutdown switch in engine compartment |
| Special Features |
Pilot operated valve option
Easy access engine compartment
12 volt accessory power outlet
On board compressed air
Single function lever or thumb switch opens/closes gate
Reversing fan
No need for travel permits
Hydraulic shift on the go
Lockable cab and engine compartment doors
Dual in-tank hydraulic oil filters |
Pilot operated valve option
Easy access engine compartment
12 volt accessory power outlet
On board compressed air
Single function lever or thumb switch opens/closes gate
Reversing fan
No need for travel permits
Hydraulic shift on the go
Lockable cab and engine compartment doors
Dual in-tank hydraulic oil filters |
(all specifications subject to change at any time)
|
